Solar Strings Layup: High Speed Gantry Layup Equipment
Solar Strings Layup: High Speed Gantry Layup Equipment
1 / 2
Solar Strings Layup: High Speed Gantry Layup Equipment
Solar Strings Layup: High Speed Gantry Layup Equipment

Solar Strings Layup: High Speed Gantry Layup Equipment

Customization: Available
Type: PV Module Turnkey Project Production Line
Warranty: 12 Months
Send Inquiry

Product Description

i
Basic Info Overview
Model NO.
High speed gantry layup
Beat
Full Cell ≤30sec, Half Cell ≤70sec
Transmission Speed
27m/Min
Compressed Air
0.6-0.8MPa
Rated Load
15kg
Package
Wooden Box
Specification
4580*2984*2100mm
Origin
China
★
Product Description
Solar Strings Layup Equipment
✓ Glass regulation accuracy: ≤±1mm;
✓ Cell damage rate: ≤0.1% (positive A-level cells);
✓ Fully automatically controlled equipment, requiring no manual intervention during operation;
✓ Pendulum string accuracy: front and rear spacing error ≤±0.25 mm, string spacing ≤±0.3 mm;
✓ Compatible with regular, half-cell, and MBB solar panels;
⚙
Technical Parameters
Panel sizeWidth: 900~1200mm, Length: 1600~2250mm
BeatFull cell ≤30sec, half cell ≤70sec
Transmission speed27m/min
Machine Dimension4580*2984*2100mm
Compressed Air0.6-0.8Mpa
Rated load15kg
Humidity≤80% (no condensation)
Usage environment25±5ºC
Voltage3ψ5W, 380V, 50/60Hz
Power3.6KW
Weight2470KG
⚓
Packaging & Shipping
Logistics
Packaging
Profile
Industrial Excellence
Production Workshop

Our operation adheres to the principle of quality first, customer first. We prioritize manufacturing precision and equipment reliability as the foundation of our enterprise. With dedicated finishing and roughing workshops, we ensure the highest standards for part processing.

Established as a pioneer in photovoltaic module production equipment, we provide comprehensive turnkey solutions for solar module manufacturers. Our product range includes automatic production lines, multi-layer laminating machines, robot typesetting systems, and frame integrated machines.

Our technology is compatible with all major solar cell production techniques, including Conventional, Double Glass, Half-Cut, MBB, Shingled, Heterojunction, and Topcon processes.

Advantage 1
Advantage 2
?
Frequently Asked Questions
1. What is the maximum production speed for solar cells?
The equipment achieves a beat of ≤30 seconds for full cells and ≤70 seconds for half cells.
2. Which solar panel types are compatible with this layup machine?
It is fully compatible with regular modules, half-cell, MBB, double-glass, shingled, and Topcon production processes.
3. How accurate is the glass regulation?
The glass regulation accuracy is maintained at ≤±1mm to ensure high-quality module assembly.
4. Does the machine require manual operation?
No, the equipment is fully automatically controlled, ensuring high efficiency and reducing labor costs.
5. What are the power and air requirements?
The system requires 3.6KW of power (380V, 50/60Hz) and a compressed air pressure of 0.6-0.8MPa.
6. What is the cell damage rate during the process?
The equipment is designed for high precision, keeping the cell damage rate below ≤0.1% for positive A-level cells.
