Framing Machine: Trinity Solar Framing Equipment

1 / 2

Framing Machine: Trinity Solar Framing Equipment

Customization:	Available
Type:	PV Module Turnkey Project Production Line
Warranty:	12 Months

Send Inquiry

Product Description

ℹ

Basic Information

Model: Trinity solar framing machine

Weight: 3200kg

Cycle Beat: ≤30 S

Transmission: 0~20m/Min

Humidity: ≤80%

Dimensions: 5600*3200*2500mm

⚙

Product Description

The glue overflow is even and bubble-free and has the function of corner pressing.

Precision Engineering: Plane error ≤0.5mm, long/short side error ±0.5mm, diagonal size error ≤1mm.

The all-in-one framing and gluing machine is composed of three systems working via I/O signal docking.

Host PLC communicates with the servo through CANopen; equipped with HMI for easy parameter setting.

Equipment formula parameters allow for quick switching between different component specifications.

Equipped with frame-sensing devices on all four sides to ensure stable operation.

Integrated suction cups vacuum the panel before framing to improve flatness and glue distribution.

📊

Technical Parameters

Panel Size Range	Length (1634-2500 mm) Width (986-1400mm)
Production Beat	≤30 s
Transmission Speed	0~20M/min
Compressed Air	0.6-0.8Mpa
Voltage Supply	3ψ5W, 380V, 50/60Hz
Power Consumption	5370W + 5750W
Operating Temp	25±5ºC

📦

Packaging & Shipping

🏢

Professional Manufacturing

The manufacturer adheres to the principle of quality first and customer satisfaction. Quality and reputation are considered the life of the enterprise. We serve customers with excellent products and a comprehensive service system covering pre-sales, mid-sales, and after-sales stages.

Equipped with independent finishing and roughing workshops, we ensure the precision and quality of parts processing. An experienced production and assembly team guarantees production progress and reliable service. Established in 2008, the enterprise is a pioneer in photovoltaic module production equipment, integrating R&D, manufacturing, and installation.

Turnkey solutions are provided for fully packaged production lines. Equipment includes automatic production lines, multi-layer laminating machines, robot typesetting machines, and frame integrated machines compatible with Conventional, Double Glass, Half-Cut, MBB, Shingled, Topcon, and other solar module types.

⭐

Our Advantages

❓

Frequently Asked Questions

What is the production speed of the framing machine?

The machine operates with a beat of ≤30 seconds per panel, with a transmission speed of 0-20m/min.

What size of solar panels can this equipment handle?

It supports panel lengths from 1634mm to 2500mm and widths from 986mm to 1400mm.

How is framing precision ensured?

The machine achieves high precision with a plane error of ≤0.5mm and a diagonal size error of ≤1mm, aided by vacuum suction cups for flatness.

Is the machine compatible with different solar technologies?

Yes, it is designed for Conventional, Double Glass, Half-Cut, MBB, Shingled, Heterojunction, and Topcon modules.

Does the system allow for quick specification changes?

Yes, the HMI interface and PLC system include equipment formula parameters that allow customers to switch specifications quickly.

What type of maintenance and after-sales support is available?

We provide comprehensive after-sales support with experienced engineers available to address complex machine problems within 6 to 12 hours in key markets.
